56 HMX Extender System Installer/User Guide
5. To confirm your selection and exit the screen, type 0 (zero) and press Enter.
OSD Inactivity Time-out
By default, the HMX user station is configured to dismiss the OSD after an inactivity period of 10
minutes. To reactivate the OSD, you must enter a valid OSD hotkey sequence.
Using the serial menu, you can disable the OSD time-out or change the time-out period to any
value between zero minutes and 10 hours. Setting the time-out period to zero means that the OSD
will not time out. The maximum time-out period that can be configured is 9 hours and 59 minutes.
NOTE: You can dismiss the OSD at any time by pressing ESC.
To change the OSD time-out period:
1. From the serial menu, press 1 to access the Receiver Main Menu and press Enter. If the
password option is enabled, you will be prompted for a password. Press
8 to access the
Console Settings Menu and press
Enter. The current OSD time-out configuration is displayed
beside menu item 2.
Figure 3.36: Receiver Console Settings Menu
Table 3.2: OSD Hotkey Sequences
Hotkey Sequences
All Print Screen (Default)
Ctrl + Ctrl (L - R) Ctrl + Ctrl (L)
Ctrl + Ctrl (R) Alt + Alt (L - R)
Alt + Alt (L) Alt + Alt (R)
Shift + Shift (L - R) Shift + Shift (L)
Shift + Shift (R) Scroll Lock + Scroll Lock
