Avocent HMX User Manual

Chapter 3: Operations 59
4. Type the number that corresponds to the audio setting you wish to apply and press Enter.
NOTE: If you choose off, audio support will be disabled.
5. To confirm your selection and exit the screen, type 0 (zero) and press Enter. The unit resets
after you press
Enter.
Display power saving mode
By accessing the HMX Manager appliance, you can set and display the power saving mode feature.
To set up the display power saving mode feature:
1. From the serial menu, press 1 to access the Receiver Main Menu and press Enter. If the
password option is enabled, you will be prompted for a password. Press
8 to access the
Console Settings Menu and press
Enter. The current Power Saving configuration is displayed.
2. Press 8 to choose Display Power Saving Mode, then press Enter. The Display Power Saving
Mode Menu will appear.
Figure 3.40: Display Power Saving Mode Menu
3. Enter the number representing the desired mode from the menu.
4. To confirm your selection and exit the screen, type 0 (zero) and press Enter.
Setting the Auto Logout Timeout (Serial Menu)
If there is no keyboard or mouse activity for an amount of time greater than the value set in the
Auto Logout Timeout, the user station will automatically disconnect from the transmitter and log
off from the HMX Manager.
1. From the serial menu, press 1 to access the Receiver Main Menu and press Enter. If the
password option is enabled, you will be prompted for a password. Press
8 to access the
Console Settings Menu and press
Enter. The current session Auto logout is displayed beside
menu item 9.

Avocent HMX Specifications

General

Type	KVM extender
Resolution Support	Up to 1920x1200
USB Support	Yes
Distance	Up to 100 meters
Video Interface	DVI
Audio	Yes
Power Supply	External
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
