14 HMX Extender System Installer/User Guide
Connecting power
The HMX 1050 user station features an external power supply. A DC power jack is located on the
rear of the HMX 1050 user station.
NOTE: Use only the power supply provided by Avocent.
To connect power to the HMX 1050 user station:
1. Plug the external power supply’s 2.5 mm connector into the DC power jack on the rear of the
HMX 1050 user station.
2. Connect the detachable IEC power cord to the power supply.
3. Plug the IEC power cord into an appropriate wall outlet.
Networked installation
The following instructions will enable you to install your HMX 1050 user station and HMIQDI
transmitter in a networked configuration. In this installation, multiple HMIQDI transmitters and
HMX 1050 user stations are attached via the same Ethernet network. In this case, it is important for
each unit to be configured with a unique IP address.
NOTE: In Desktop and Extender Modes, the HMX 1050 user station and HMIQDI transmitter can obtain their IP
address data from a DHCP server.
HMIQDI transmitters and HMX 1050 user stations may be configured for use on a single subnet or
for use across routers. Use of routers, however, will cause a slight increase in end-to-end latencies,
which may not be acceptable for all applications.
8 Local Peripherals
(attached via USB)
9 HMIQDI Transmitter
Table 2.3: Figure 2.3 Descriptions (Continued)
Number Description
