28 HMX Extender System Installer/User Guide
3. Click the Info tab to view system information for your user station and transmitter.
4. Click the Rcvr radio button to view the system information for your user station.
Figure 3.3: User Station Connected to Transmitter
-or-
Click the Trans radio button to view the system information for your transmitter.
NOTE: If there is no transmitter connected, the Trans radio button option will display as No Target.
To initiate a connection with a remote computer in Extender Mode:
1. Press Print Screen.
2. Enter the Login Name and Password, ensuring that the appropriate keyboard has been selected.
3. Click the OK button. If the user has access to only one target computer, the login progress
message will then appear and a connection will be established.
Figure 3.4: Login Screen
Login
Login Name
Password
Cancel
US English
Keyboard
Country
OK

Avocent HMX Specifications

General

Type	KVM extender
Resolution Support	Up to 1920x1200
USB Support	Yes
Distance	Up to 100 meters
Video Interface	DVI
Audio	Yes
Power Supply	External
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
