80 HMX Extender System Installer/User Guide
Supported Hardware
Video Resolution
640 x 350 @ 85 Hz
640 x 480 @ 60 Hz, 72 Hz, 75 Hz, 85 Hz
720 x 400 @ 70 Hz, 85 Hz
800 x 600 @ 60 Hz, 72 Hz, 75 Hz, 85 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz, 85 Hz
1152 x 864 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 Hz
1680 x 1050 @ 60 Hz
The following widescreen resolutions are also supported:
1360 x 768 @ 60 Hz
1280 x 720 @ 50 Hz, 60 Hz
Video Standard DDC version 2B
Color Depth 24 Bit
Audio Standard PC99
Audio Performance
High Performance Line-out:
44.1 kHz over stereo channels at a resolution of 16 bits
Microphone:
44.1 kHz over a single channel at a resolution of 16 bits
Medium Performance Line-out:
8 kHz over stereo channels at a resolution of 16 bits
Microphone:
8 kHz over a single channel at a resolution of 16 bits
Target Sync Types
(Analog input only)
Separate horizontal and vertical
EDID table settings Normal aspect or wide screen resolutions
Safety and
EMC Approvals and
Markings
UL, FCC, cUL, VCCI, C-Tick, CE
Table A.4: HMIQDI Transmitter Product Specifications (Continued)
