Axel Oxygen 5 Operating Manual

Oxygen 5
Pag. 39
9 TIMER (optional)
By request, up to two Timer modules are available to be installed on the mixer cover. The Timer feature the
time count up showing minutes, seconds and tenth of seconds if time duration does not exceed 1 hour and
hours, minutes and seconds if time duration exceeds 1 hour.
In particular, you can associate the two timers to the opening of the slider on Mono modules and to the
Start/Stop function of the Stereo modules.
Through internal jumper setting two operation modes are available:
• reset + count start at every slider opening
• manual count start/stop regardless of the slider position and of the On/Off state of Mono modules
10 TECHNICAL SPECIFICATIONS
STEREO MODULE
INPUT A Stereo Line El. Bal. Jack -15 ÷ +15 dB
INPUT B Stereo Line (jumper select) El. Bal. Jack -15 ÷ +15 dB
Stereo Phono (jumper select) Unbal. Jack -15 ÷ +15 dB RIAA
MONO MODULE
INPUT A Mono Micro (gain adj. -40÷-80 dB) El. Bal. XLR -15 ÷ +15 dB
INSERT A Mono Line Unbal. Jack 0 dB
INPUT B Mono Line El. Bal. Jack -15 ÷ +15 dB
TELCO MODULE
SEND Mono Line El. Bal. Jack -15 ÷ +15 dB
RECEIVE Mono Line El. Bal. Jack -15 ÷ +15 dB
REC OUT Mono Line El. Bal. Jack 0 dB
SUB MODULE
EXT IN Stereo Line El. Bal. Jack
-∞ ÷ +15 dB
SUB Output Stereo Line El. Bal. Jack 0 dB
INSERT Stereo Line Unbal. Jack 0 dB
REC1 – REC2 Stereo Line El. Bal. Jack 0 dB
MASTER MODULE
TUNER IN Stereo Line El. Bal. Jack -15 ÷ +15 dB
MASTER Output Stereo Line El. Bal. Jack 0 dB
STUDIO Output Spk - Stereo Line Unbal. Jack
-∞ ÷ +15 dB
Phones - Stereo Line Unbal. Jack 0 ÷ +44 Vpp Amplified
CTRL ROOM Output Spk - Stereo Line Unbal. Jack
-∞÷+15 dB
Phones - Stereo Line Unbal. Jack 0 ÷ +44 Vpp Amplified
GENERAL FEATURES
HEIGHT 220 mm
DEPTH 595 mm
WIDTH 745 mm (frame 18) - 1050 mm (frame 26)
WEIGHT depending on the number of installed modules
