Oxygen 5
Pag. 16
3.16 MODULE CONFIGURATION
On the MONO module board you find 10 Jumpers allowing different operation modes and functions.
To change a jumper setting, please:
switch off the console (every intervention on the modules always requires the mixer switching off !)
remove the module
disconnect the flat cable (pay attention to the two little hooks placed at the connector edges)
alter the setting position as showed by the following table
connect again the flat cable and lock the hooks
insert the module into the console mainframe
turn on the console
Please refer to the following figure and to the ‘Factory preset jumper configuration’ chapter at the
end of this manual before altering jumper configurations.
