Axis AGN50 - General Balance View

USER MANUAL 5
____________________________________________________________________________________________________________________
4. General balance view
1 – pan
2 – pan support
3 – pan ring
4 – floor of weighing chamber
5 – keys
6 – rotating legs
7 – water level
8 – graphical display
9 – weighing chamber
7
6
1
2
8
4
3
5
9
