Azbil CorporationNo. SS2-AVP702-0100
Item Specication
Approvals FM Intrinsically safe (ic) and Nonincendive
Intrinsically safe (ic) (Zone system)
Class I, Zone 2, AEx ic IIC T4
Entity Parameters:
Positioner Circuit: Ui=30V, Ii=100mA, Pi=1W, Ci=24nF, Li=0.22mH
Transmitter Circuit (AVP701): Ui=30V, Ii=100mA, Pi=1W, Ci=20nF, Li=0.22mH
Nonincendive (Division system)
Class I, Division 2, Group A, B, C and D, T4
Nonincendive Field Wiring Parameters:
Positioner Circuit: Vmax=30V, Imax=100mA, Ci=24nF, Li=0.22mH
Transmitter Circuit (AVP701): Vmax=30V, Imax=100mA, Ci=20nF, Li=0.22mH
Suitable
Class II and Class III, Division 2, Group E, F and G, T4
Indoor/Outdoor Enclosure: NEMA Type 4X, IP66
FMC Explosionproof/Dust Ignition Protection
Explosionproof (Division system): Class I, Division 1, Group C, D T6
• Factory sealed, conduit seal not required
• Not including gasoline atmospheres
Flameproof (Zone system): Class I, Zone 1, Ex d IIB T6
• Seal all conduits within 450mm (18 inches)
Dust ignition protection (Division system): Class II, III, Division 1, Group E, F, G T6
Enclosure classication: IP66
ATEX Flameproof/Dust Ignition Protection
Flameproof: II 2 G Ex d IIC T6 Gb
Dust ignition protection: II 2 D Ex tb IIIC T85°C Db
Enclosure classication: IP66
Cables glands or conduit sealing devices used must be certied for the Ex d IIC protec-
tion.
Use the product with the degree of protection IP66 under the IP66 required environment.
ATEX Intrinsically safe/Dust Ignition Protection
Intrinsically safe: II 1 G Ex ia IIC T4 Ga
Dust ignition protection: II 1 D Ex ia IIIC T135°C Da
Enclosure classication: IP66
e barriers should be ATEX certied types and comply with the following conditions:
Input Signal Terminals (+/- IN):
Ui=30 V, Ii=93 mA, Pi=0.9 W, Ci=4 nF, Li=220 μH
Output Signal Terminals (+/- OUT):
(AVP701) Ui=30 V, Ii=93 mA, Pi=0.9 W, Ci=22 nF, Li=220 μH
IECEx Flameproof/Dust Ignition Protection
Flameproof: Ex d IIC T6 Gb
Dust ignition protection: Ex tb IIIC T85°C Db
Enclosure classication: IP66
Cables glands or conduit sealing devices used must be certied for the IECEx Ex d IIC
protection.
Use the product with the degree of protection IP66 under the IP66 required environment.
IECEx Intrinsically safe/Dust Ignition Protection
Intrinsically safe: Ex ia IIC T4 Ga
Dust ignition protection: Ex ia IIIC T135°C Da
Enclosure classication: IP66
e barriers should be IECEx certied types and comply with the following conditions:
Input Signal Terminals (+/- IN):
Ui=30 V, Ii=93 mA, Pi=0.9 W, Ci=4 nF, Li=220 μH
Output Signal Terminals (+/- OUT):
(AVP701) Ui=30 V, Ii=93 mA, Pi=0.9 W, Ci=22 nF, Li=220 μH
NEPSI Flameproof / Dust Ignition Protection
Flameproof: Ex d IIC T6 Gb
Dust ignition protection: DIP A21 T
A
85°C
Enclosure classication: IP66
Cables glands or conduit sealing devices used must becertied for the Ex d IIC or DIP
A21 protection.
Use the product with the degree of protection IP66 under the IP66 required environment.
KOSHA Flameproof Ex d IIC T6
Cable glands or conduit sealing devices used must be certied for the Ex d IIC protection.
