Azbil 700 series - List of Default Values for Internal Data

6-9
6-7 List of Default Values for Internal Data
Item Parameter Default
Device tag Device Tag XXXXXXXX
Long tag Long Tag
Number of characters:
32
Input value to fully open
the valve
Input Range High
(Open)
20mA
Input value to fully close
the valve
Input Range Low
(Close)
4mA
Actuator type Actuator Type Linear
Position of valve when
fully closed
Valve Closed Position FeedBack Lever Down
Whether a booster relay is
provided
Booster relay Without Booster Relay
Feedback lever operation Feedback Lever Motion UP when Po1 increases
Pilot relay type Pilot Relay Type Single Acting
Positioner operation Positioner Action Direct
Electrical fail direction Electrical Fail to Close
Actuator size Actuator Size Param 1
Friction level Friction Level Heavy
Control deadband Control Deadband 0.05
Controlled parameter
Proportional gain
(beyond GAP1)
P out of GAP1 1
Integral time
(beyond GAP1)
I out of GAP1 10
Differential time
(beyond GAP1)
D out of GAP1 0.2
GAP width 1 GAP1 5
Proportional gain
(within GAP1)
P inside of GAP1 0.5
Integral time (within
GAP1)
I inside of GAP1 5
Differential time
(within GAP1)
D inside of GAP1 0.2
GAP width 2 GAP2 1
Proportional gain
(within GAP2)
P inside of GAP2 0.2
Integral time (within
GAP2)
I inside of GAP2 2
Differential time
(within GAP2)
D inside of GAP2 0.2
Flow amount
characteristic
Input Characterization Linear
Forced fully open value Travel Cutoff High 109
Forced fully closed value Travel Cutoff Low 0.5
Pressure display unit Unit of Pressure kPa
