Azbil 700 series User Manual

D-1
Appendix D Model Selection
No. SS2-AVP702-0100Azbil Corporation
MODEL SELECTION
Basic model number
AVP701
Analog signal (4 to 20 mA DC) with Travel Transmission and HART com-
munication Protocol
-
(1) (2) (3) - (4) (5) (6) (7) - (8) (9)
AVP702 Analog signal (4 to 20 mA DC) with HART communication Protocol
(1) Structure
Water-proof X
TIIS Flameproof (Electrical connection G1/2 only) with cable gland * E
FM Explosionproof/Dust ignition protection (Electrical connection G1/2 is not available.) F
FM Intrinsically safe (ic) and Nonincendive V
FMC Explosionproof/Dust ignition protection (Electrical connection G1/2 is not available.) A
ATEX Flameproof/Dust ignition protection (Electrical connection G1/2 is not available.) C
ATEX Intrinsically safe/Dust Ignition Protection L
IECEx Flameproof/Dust ignition protection (Electrical connection G1/2 is not available.) D
IECEx Intrinsically safe/Dust Ignition Protection T
NEPSI Flameproof/Dust ignition protection (Electrical connection G1/2 is not available.) N
KOSHA Flameproof (Electrical connection G1/2 is not available.) K
EAC Flameproof (Electrical connection G1/2 is not available.) G
INMETRO Flameproof/Dust ignition protection (Electrical connection G1/2 is not available.) B
(2) Connection
Electrical connection Air piping connection Mounting thread Pressure gauge thread
G1/2 Rc1/4 M8 Rc1/8
G
1/2NPT 1/4NPT M8 Rc1/8
N
M20×1.5 1/4NPT M8 Rc1/8
M
(3) Finish
Standard (Baked acrylic) S
Corrosion proof (Baked urethane) B
(4) (5) Display
Display with push button D X
(6) Diagnostic
Advanced Diag (with four pressure sensors) A
(7) Overvoltage
protection
None X
Overvoltage protection (Input impedance +125 ) V
(8) (9) Option
None X X
Explosion-proof universal elbow (SUS304 G1/2) (1) A A
Explosion-proof universal elbow (SUS304 G1/2) (2) A C
Model KZ03 pressure regulator with lter (Mounted on Positioner)
*2
M 1
Model KZ03 pressure regulator with lter (with bracket for separated mount) M 2
Model KZ03 pressure regulator with lter (with bracket for separated mount onto horizontal-installed actuator) M 3
Extension lever (In case of without mounting bracket) M L
Seal tape prohibited M J
Mounting bracket material SUS316
*3
M 6
Mounting bracket (PSA,1,2,PSK1) Y S
Mounting bracket (New model PSA3, 4 (produced aer 2000), VA1 to 3(produced aer May. ‘83)) Y Q
Mounting bracket (PSA6, VA4 to 6(produced aer May. ‘83)) Y L
Mounting bracket (PSA7) Y 8
Mounting bracket (HA1) Y A
Mounting bracket (HA2, HL2) Y T
Mounting bracket (HA3, HL3) Y C
Mounting bracket (HA4, HL4) Y N
Mounting Bracket (VR1) Y V
Mounting Bracket (VR2, 3) Y R
Mounting Bracket (VR3H) Y 6
Mounting Bracket (RSA1) Y F
Mounting Bracket (RSA2) Y U
Mounting Bracket (old model PSA3, 4 (those produced before 1999)) Y Y
Mounting Bracket (VA1 to 3 (produced before Apr. ‘83, former model Motion Connector), 800-1, 2, 3)
*4
Y W
Mounting Bracket (VA4,5(produced before Apr. ‘83, former model Motion Connector), 800-4, 5)
*4
Y J
Mounting Bracket (VP5,6) Y 1
Mounting Bracket (VP7) Y 7
Mounting bracket (DAP560, 1000, 1000X (stroke: 100mm max.)) Y 4
Mounting bracket (DAP1500, 1500X (stroke: 100mm max.)) Y 5
*1. One set of TIIS Flameproof cable gland shall be attached for model AVP702. Two sets are for model AVP701.
*2. Select the code “M1” only when the direction of drain of the pressure regulator with lter on the control valve is downward(ground).
Not available code “M1” when AVP is installed with the LCD facing upwards.
*3. Material of mounting bracket when you don’t select code”M6” is SUS304.
*4. Consult with sales representative in case of no mounting hole on the side of valve yoke.
7
