4-2-21 Control Valve Diagnostic Messages
The device has a control valve diagnostic function. Select [Device]→[Diagnostics]→[Diag
nostic Status]→[Valve Diagnostic].
Table 4-6 Control Valve Diagnostic Messages List
Message
OutofSpecification SupplyPressureHighAlarm
SupplyPressureLowAlarm
TempHighAlarm
TempLowAlarm
Deviation+Alarm
Deviation-Alarm
ZeroTravel+Alarm
ZeroTravel-Alarm
MaintenanceRequired TotalStrokeAlarm
CycleCountAlarm
ShutCountAlarm
MaxTvlSpeed+Alarm
MaxTvlSpeed-Alarm
PoValidity+Alarm
PoValidity-Alarm
MaxFrictionAlarm
Stick-SlipHighAlarm
Stick-SlipMediumAlarm
Stick-SlipLowAlarm
