Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
Display Item Contents
Initial value
Notes
Internal event 1
Configuration 1
0: No event
1: PV high limit
2: PV low limit
3: PV high/low limit
4: Deviation high limit
5: Deviation low limit
6: Deviation high/low limit
7: Deviation high limit
(Final SP reference)
8: Deviation low limit
(Final SP reference)
9: Deviation high/low limit
(Final SP reference)
10: SP high limit
11: SP low limit
12: SP high/low limit
13: MV high limit
14: MV low limit
15: MV high/low limit
16: CT1 heater burnout/over-
current
17: CT1 heater short-circuit
18: CT2 heater burnout/over-
current
19: CT2 heater short-circuit
20: Loop diagnosis 1
21: Loop diagnosis 2
22: Loop diagnosis 3
23: Alarm (status)
24: READY (status)
25: MANUAL (status)
26: Invalid
27:
During AT execution (status)
28: During SP ramp (status)
29:
Control direct action (status)
30:
During ST execution (status)
31: Invalid
32: Timer (status)
33:
High and low limits of MFB value
(Invalid in this unit)
0
Internal event 1
Configuration 2
3rd digit 1st digit
4th digit 2nd digit
As described below.
1st digit: Direct/
Reverse
0: Direct
1: Reverse
0
2nd digit: Standby 0: None
1: Standby
2: Standby + Standby at SP
change
0
3rd digit: Operation at
READY
0: Continue
1: Forced OFF
0
4th digit: Undefined 0 0
Handling Precautions
• If ROM version 1 of the instrument information bank (
I
d02
) is prior to 2.04,
“33” cannot be set as [Internal Event configuration 1 operation type].
