7-19
Chapter 7. SPECIFICATIONS
• Separate display unit Unit: mm
OK
SP
PV
m
3
Digital
Mass Flow
Controller
L/ min
ALM EV1 EV2
RUN ENT DISP
88
45.8
29.3
1.6
38
33
105
93
5
4.5
12.5
M4(2)
6
19
(R)
Mounting panel cutout dimensions (recommended)
100 ± 0.2
50 ± 0.2
45 ± 0.2
90 ± 0.2
35
±
0.2
17.5
±
0.2
z
Cable for connecting display to main unit Unit: mm
2000 min.
Oki Electric Cable Company, Limited FLEX-S16-7/0.127-2651P
Color: pin No.1, red; pin Nos. 5, 10 and 15, green; others, gray
Red
HIROSE ELECTRIC CO., LTD. HIF3BA-16D-2.54R
