Bacharach PCA 400 - Page 68

0024-9551 Revision 1
68
PCA
®
400 User Manual
Field Column Name Data Name or Value
1 Date Date of Test (MM/DD/YY)
2 Time Time of Test (12-Hour Format)
3 Folder Information Input by User
4 Subfolder Information Input by User
5 Fuel Fuel Name
6 % O
2
Oxygen Level
7 CO Carbon Monoxide Level (See Field 27)
8 ppm CO (O
2
) Carbon Monoxide Reference to a % of O
2
(See Field 24)
9 % Eciency Combustion Eciency
10 % CO
2
Carbon Dioxide Level
11 % EA Excess Air
12 TStk Stack Temperature
13 TAir Primary / Ambient Air Temperature
14 Delta-T Dierential Temperature Value
15 TempUnit Temperature Units
16 NO Nitric Oxide Level (See Field 27)
17 ppm NO (O
2
) Nitric Oxide Level Referenced to a % of O
2
(See Field 25)
18 NO
2
Nitric Dioxide Level (See Field 27)
19 ppm NO
2
(O
2
) Nitric Dioxide Level Referenced to a % of O
2
(See Field 25)
20 NO
x
Nitrogen Oxide (NO + NO2, See Field 27)
21 ppm NO
x
(O
2
) Nitrogen Oxide Level as Referenced to a % of O
2
(See Field 25)
22 SO
2
Sulfur Dioxide (See Field 27)
23 ppm SO
2
(O
2
) Sulfur Dioxide Level Referenced to a % of O
2
(See Field 26)
24 CO_O
2
Ref % O
2
Reference for CO
25 NO
x
_O
2
Ref % O
2
Reference for NO
x
26 SO
2
_O
2
Ref % O
2
Reference for SO
2
27 Pollution Units Pollution Units of Measure
(1)
28 Pressure Pressure (Draft) Value
29 Pressure Units Pressure Units of Measure
(2)
(1)
Pollution units as selected (Section 3.2.1).
(2)
Pressure units as selected (Section 3.3.1).
The table below contains listings and descriptions of the 32 data elds that are downloaded
with each data record. Note that for sensors that are not installed, all related data elds for
those sensors will be marked as “***”. For example, if the analyzer does not contain an SO
2
sensor, then “***” will appear in data elds 23 and 24.
Downloaded Data Fields
