Bacharach PCA 400 User Manual

0024-9551 Revision 1
8
PCA
®
400 User Manual
CAUTION: When the instrument is used in an inecient furnace or boiler application
where there is a high soot concentration, the probe’s sample lter may become
clogged. Before every use check the lter to conrm that it is clean or replace it with
a new lter.
CAUTION: Never disconnect the probe from the instrument until purging is complete.
Otherwise, leftover target gas (for example, CO) may remain in the probe and cause
inaccurate zeroing at power up that could lead to inaccurate gas measurements
afterwards.
1.4 Product Overview
The PCA
®
400 is an industrial-grade, hand-held combustion and emissions analyzer
for on-demand and / or semi-continuous sampling of commercial and light industrial
appliances (furnaces, boilers and engines).
Standard Product Conguration
The base instrument is supplied with a probe and hose assembly, factory calibrated / installed
sensors, printer interface, hard carry case, lters, USB cable, PC Software (digital download),
AC adapter and a rechargeable lithium-ion battery pack. The reporting kit version (in addition
to the base) includes an IrDA + Bluetooth
®
printer and printer paper.
Intended Product Applications
The intended purpose of the measuring device is for:
• Engineerings servicing / monitoring industrial combustion plants process systems,
power stations
• Emissions inspectors, Engine manufacturers and operators, service engineers &
mechanics of burner /boiler manufacturers in the industrial sector.
Typical measuring tasks and particular characters of the PCA
®
400 include:
• Measurement on industrial engines (CO / NO dilution)
• Measurement on gas turbines (High precision CO and NO plus optional dilution).
• Emissions measurements (integrated ow speed and dierential pressure measurement)
The PCA
®
400 has not been designed for and SHOULD NOT be used for the following:
• Continuous measurements over 5-hours
• As a safety (alarm) instrument.
CAUTION: Except for sensor and battery replacement, this analyzer should only be
opened and / or serviced by authorized Bacharach personnel. Failure to comply may void
the warranty.
