Badger Meter ModMAG M2000 User Manual

M2000 register write properties Page 27/30
MID_M2000_BA_MODBUS_02_1805
No
Register
name
Register
address
Min.
value
Max.
value
Value definition
** Req.
Action
request
75
Output #4:
Flow alarm
minimum [%]
0x00B8 0 100
1 = 1%
100 = 100%
76
Output #4:
Flow alarm
maximum [%]
0x00B9 0 100
1 = 1%
100 = 100%
YES
77
Output #4:
Output mode
0x00BA 0 1
0 = Normally open
1 = Normally closed
YES
78
Output #4:
Hardware
select
0x00BB 0 1
0 = Relay
1 = Open collector
YES
79
Output #4:
Output
operation
0x00BC 0 11
0 = Off
1 = Flow alarm
2 = Empty pipe alarm
3 = Error alarm
4 = Forward pulse
5 = AMR pulse
6 = Reverse pulse
7 = Frequency output
8 = Preset batch output
9 = Flow direction
10 = Verification test
11 = 24V DC supply
YES
138
Display
backlight mode
0x010F 0 2
0 = Forced on
1 = Forced off
0 = Timed off
YES
139
Preset batch
amount [m
3
]
0x0110 0
295735.2
95
295735.295 m
3
=
9,999,999,999 Oz
YES
140
Menu reset
allowed
0x0112 0 1
1 = All totalizers are
resetable
0 = otherwise
YES
141
Menu
language
settings
0x0114 0 1
0 = English
1 = Alternate
YES
142
File system –
Number of
records to read
0x0117 0 10000
# of records to extract
from memory token
NO
146
Analog input
measurement
counter
0x0119 0 0 -- NO
148
Empty pipe
calibration
[volts]
0x011E 0 3 -- YES

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
