Baldor DBSC 100 Series User Manual

Section
2–2
MN1229
General Specifications - 230VAC
Description Unit DBSC102-AAA DBSC105-AAA
Input V oltage Range
(230V
AC 1  Nominal)
VAC 220 - 250
Input Frequency Hz 50/60 ±5%
Nominal Output Bus (Range) VDC 320 (50-350)
Nominal Current ( ±10%) A
RMS
2.5 5
1
Peak Phase Current ( ± 10%); 2.5s ±
.5s
A
RMS
5 10
Nominal Output Power KVA 1.01 2.17
Efficiency % >97
Minimum Load Inductance H 400
Nominal Switching Frequency KHz 8.5
Mounting – Panel
Overall Dimensions in (mm) 2.65x6.81x6
(67.5x173x152.5)
3.6x6.8x6
(92.5x173x152.5)
Weight lbs (Kg) 2.73 (1.24)
(without heatsink)
4.69 (2.13)
(with heatsink)
Operating Altitude Feet
(Meters)
To 3300 feet (1000 meters).
Above 3300 ft, derate 11% per
3300ft (1000m).
Operating T emperature °C
+5 to 40
Rated Storage T emperature °C –25 to +70
1
DBSC 105 with additional heatsink.
All values at ambient temperature of 25°C unless otherwise stated.
General Specifications - 230VAC
Description
Input Voltage Range
(230VAC 10 Nominal)
Input Frequency
Nominal Output Bus (Range)
Nominal Current (±10%)
Peak Phase Current (±10%); 2.5s ±
.5s
Nominal Output Power
Efficiency
Minimum Load Inductance
Nominal Switching Frequency
Mounting
Overall Dimensions
Weight
Operating Altitude
Operating Temperature
Rated Storage Temperature
Unit
VAC
Hz
VDC
ARMS
ARMS
KVA
0/0
itH
KHz
in (mm)
lbs (Kg)
Feet
(Meters)
oc
oc
DBSC102-AAA DBSC105-AAA
220 - 250
50/60 ±5%
320 (50-350)
2.5
5
51
10
1.01 2.17
>97
400
8.5
Panel
2.65x6.81x6 3.6x6.8x6
(67.5x173x152.5) (92.5x173x152.5)
2.73 (1.24) 4.69 (2.13)
(without heatsink) (with heatsink)
To 3300 feet (1000 meters).
Above 3300 ft, derate 11% per
3300ft (1000m).
+5 to 40
—25 to +70
1 DBSC 105 with additional heatsink.
All values at ambient temperature of 25°C unless otherwise stated.
2-2 MN1229
