Baldor DBSC 100 Series User Manual

Section
3–4
MN1229
Motor Wiring
Connect the motor leads as follows:
1. Connect motor phase U to X1-U.
2. Connect motor phase V to X1-V.
3. Connect motor phase W to X1-W.
Control Signal Wiring
All wiring from external devices to the control are made at the connectors
shown in Figure 3-1.
The inputs at X3 pins 7, 9, 10, 11 and 12 can be wired for active high or active
low conditions. Pin 7 is the CREF (Control Input Reference) point.
Active High Definition
If the Control Inputs are to be wired as Active High, CREF is connected to
GND. When a control input is at +24VDC (range +12VDC to +29VDC), it is
active and when it is at GND it is inactive. Figure 3-2 shows this relationship.
Active Low Definition
If the Control Inputs are to be wired as Active Low, CREF is connected to
+24VDC (range +12VDC to +29VDC). When a control input is at GND, it is
active and when it is at +24VDC it is inactive. Figure 3-2 shows this
relationship.
Table 3-1 Control Inputs
Signal Connector Active Condition Inactive Condition
Enable X3-9 Control Enable Control Disabled
CW Limit X3-10 CW Rotation Enabled CW Rotation Disabled
CCW Limit X3-11 CCW Rotation Enabled CCW Rotation Disabled
Hold X3-12 Hold function is Active Hold function is not
active
Motor Wiring
Connect the motor leads as follows:
1. Connect motor phase U to X1-U.
2. Connect motor phase V to X1-V.
3. Connect motor phase W to X1-W.
Signal Connector Active Condition Inactive Condition
Enable
X3-9
Control Enable Control Disabled
CW Limit X3-10 CW Rotation Enabled CW Rotation Disabled
CCW Limit X3-11 CCW Rotation Enabled CCW Rotation Disabled
Hold X3-12 Hold function is Active Hold function is not
active
Control Signal Wiring
All wiring from external devices to the control are made at the connectors
shown in Figure 3-1.
The inputs at X3 pins 7, 9, 10, 11 and 12 can be wired for active high or active
low conditions. Pin 7 is the CREF (Control Input Reference) point.
Active High Definition
If the Control Inputs are to be wired as Active High, CREF is connected to
GND. When a control input is at +24VDC (range +12VDC to +29VDC), it is
active and when it is at GND it is inactive. Figure 3-2 shows this relationship.
Active Low Definition
If the Control Inputs are to be wired as Active Low, CREF is connected to
+24VDC (range +12VDC to +29VDC). When a control input is at GND, it is
active and when it is at +24VDC it is inactive. Figure 3-2 shows this
relationship.
Table 3-1 Control Inputs
3-4 MN1229
