6–3
MN1229
Mounting Hole Location
Heat
Sink
Rear
V
iew
.2ʺ
(5.2mm)
6.028ʺ
(153mm)
Location of mounting hole.
Locate and drill hole in enclosure.
Mount control to enclosure.
Alternate mounting using
two (2) tabs and four (4)
screws provided.
Mounting Hole Location
-U-
0
Heat
Sink
.2" (5.2mm)
Location of mounting hole.
Locate and drill hole in enclosure.
Mount control to enclosure.
6.028"
(153mm)
Alternate mounting using
two (2) tabs and four (4)
screws provided.
0
V
Rear View
MN1229 6-3
