Section
2–5
MN1229
Regeneration
Description Unit DBSC 102 DBSC 105
Maximum REGEN Switching Current
A 7
Maximum Load Inductance H 100
REGEN Resistor for
DBSC 10X-AAA (230V
AC)
– RG56
REGEN Resistor for
DBSC 10X-AAA-1 (1
15VAC)
– RG27
Continuous REGEN Power with
230V
AC (1
15V
AC) Input V
oltage
Watts 44
REGEN Power
Watt-Sec 430
Operating Conditions
Description Unit DBSC 102 DBSC 105
Ambient Operating T
emperature °C
+5 to 40
Humidity % 10 to 90 RH Non-Condensing
(According to DIN40 040,
class F)
Altitude m 1000
Shock –
10G (DIN IEC 68-2-6/29)
Vibration –
1G (DIN IEC 68-2-6/29)
Class of Protection
–
IP20 (DIN40 050/ IEC 144
Optional 24VDC Input (Optional - Must be ordered separately)
Description Unit DBSC 102 DBSC 105
Input V
oltage Range VDC
20 to 30
Input Ripple V
oltage % ±10
Input Current (@24VDC)
A
RMS
1.75
Surge Current (at Power On for
≤100msec) A
RMS
4
DC Bus V
oltage absolute Min (Max) values
with 24V option
VDC
0 (350)
Regeneration
Description Unit DBSC 102 DBSC 105
Maximum REGEN Switching Current A 7
Maximum Load Inductance µH 100
REGEN Resistor for RG56
DBSC 10X-AAA (230VAC)
REGEN Resistor for RG27
DBSC 10X-AAA-1 (115VAC)
Continuous REGEN Power with Watts 44
230VAC (115VAC) Input Voltage
REGEN Power Watt-Sec 430
Operating Conditions
Description Unit DBSC 102 DBSC 105
Ambient Operating Temperature °C +5 to 40
Humidity % 10 to 90 RH Non-Condensing
(According to DIN40 040,
class F)
Altitude m 1000
Shock 10G (DIN IEC 68-2-6/29)
Vibration 1G (DIN IEC 68-2-6/29)
Class of Protection IP20 (DIN40 050/ IEC 144
Optional 24VDC Input (Optional - Must be ordered separately)
Description Unit DBSC 102 DBSC 105
Input Voltage Range VDC 20 to 30
Input Ripple Voltage % ±10
Input Current (@24VDC) ARMS 1.75
Surge Current (at Power On for 100rnsec) ARMS 4
DC Bus Voltage absolute Min (Max) values VDC 0 (350)
with 24V option
MN1229 2-5
