Operation
5-1
1
MN1276
Drift
If
you
know
the
input
offset
value
of
the
control,
you
may
enter
the
v
alue
manually
.
Otherwise,
you
may
initiate
automatic
offset
tuning
and
let
the
control
measure
and
set
this
value.
Click
“
Download”
when
finished.
Figure
5
-
7
Drift
Parameter
Screen
Autotune
Y
ou
may
manually
tune
the
control
(see
appendix)
or
use
autotune
to
allow
the
control
to
tune
itself.
Click
“Download”
when
finished.
Figure
5
-
8
Autotune
Screen
47
