Baldor FPX A05T User Manual

Section 9
Accessories and Options
Accessories & Options 9-1MN1276
Cables Shielded (Screened) cable provides EMI / RFI shielding and are required for
compliance to CE regulations. All connectors and other components used must
be compatible with this shielded cable.
Motor Power Cable
C
a
b
l
e
R
a
t
e
d
C
r
r
e
n
t
C
a
b
l
e
A
s
s
e
m
b
l
y
B
a
l
d
o
r
C
a
t
a
l
o
g
N
m
b
e
r
Length
Cable Rated Current
C
a
b
l
e
A
s
s
e
m
b
l
y
Description
Baldor Catalog Number
Feet Meters
Power Cable Assembly
Threaded connector
(Standard-Metric Style)
CBL015SP--FHM
CBL030SP--FHM
CBL046SP--FHM
CBL061SP--FHM
CBL076SP--FHM
CBL152SP--FHM
5
10
15
20
25
50
1.5
3.0
4.6
6.1
7.6
15.2
20 Amps
Power Cable Assembly
Quick Connect Style
CBL015SP--FHQ
CBL030SP--FHQ
CBL046SP--FHQ
CBL061SP--FHQ
CBL076SP--FHQ
CBL152SP--FHQ
5
10
15
20
25
50
1.5
3.0
4.6
6.1
7.6
15.2
Power Cable Assembly
CE Style Threaded
Connector
CBL030SP--FHCE
CBL061SP--FHCE
CBL091SP--FHCE
CBL152SP--FHCE
10
20
30
50
3.0
6.1
9.1
15.2
Power Cable
No Connectors
CBL030SP--F
CBL046SP--F
CBL061SP--F
CBL076SP--F
CBL091SP--F
CBL152SP--F
10
15
20
25
30
50
3.0
4.6
6.1
7.6
9.1
15.2
30 Amps
Power Cable
No Connectors
CBL030SP--E
CBL046SP--E
CBL061SP--E
CBL091SP--E
CBL152SP--E
10
15
20
30
50
3.0
4.6
6.1
9.1
15.2
Connectors
Mating Connector by connector number (for spare parts)
X1 -- #ASR29714 (9 pin, Female) Phoenix Part No. MVSTBW2,5/9--ST
X1 -- #ASR29715 (2 pin, Female) Phoenix Part No. MVSTBW2,5/2--ST
X3 -- #ASR16000 (20 pin, Female) Phoenix Part No. MVSTBR2,5/20--ST
X6 -- #ASR16215 (9 pin, Male)
X7 -- #ASR16215 (9 pin, Male)
X8 -- #ASR23345 (9 pin, Female) Resolver
X9 -- #ASR25828A (15 pin, Male) Encoder
