Baldor FPX A05T User Manual

Specifications & Product Data 7-5
MN1276
Encoder Input (Handwheel or Feedback)
Description Unit All
Signal Type RS422
Operating Mode A/BQuadrature
Maximum Input Frequency kHz 125
Cycle Time msec 1
Serial Interface (Option FPXAXXXX--XX2X)
Description Unit All
Communication Type RS232C (not galvanically isolated)
Transmission Rate Baud 9600 (not adjustable)
Optional Interface (Option FPXAXXXX--XX4X)
Communication Type RS485 (not galvanically isolated)
Transmission Rate Baud 9600 (not adjustable)
Regeneration (115 / 230VAC)
Description Unit FPX
A02T
FPX
A05T
FPX
A07T
FPX
A02S
FPX
A05S
FPX
A10S
FPX
A15S
Switching Threshold
115VAC
230VAC
VDC
ON: OFF:
188 - 195 183 - 188
373 - 383 362 - 372
ON: OFF:
180 200
388 375
Nominal / Peak Power (10% Duty Cycle) kW 0.25 / 2.7
Maximum Regeneration Switching Current A 10
Maximum Load Inductance
mH
100
Regeneration (400 / 460VAC)
Description Unit FP4
A02
FP4
A05
FP4
A07
FP4
A15
FP4
A20
FP4
A27
Switching Threshold 400/460VAC VDC ON: 794 OFF: 787 ON: 794 OFF: 764
Nominal / Peak Power (10% Duty Cycle) kW 0.94 / 9.4 2.9 / 29
Maximum Regeneration Switching Current A 15 45 40 80
Maximum Load Inductance
mH
100
