7-2 Specifications & Product Data MN1276
Specifications
Description Unit FPX
A02T
FPX
A05T
FPX
A07T
FPX ©
A02S
FPX ©
A05S
FPX ©
A010S
FPX ©
A015S
Input Voltage Range Nominal
Minimum
Maximum
VAC 115 / 230
92 / 184
132 / 265
Input Frequency Hz 50/60 "5%
Nominal Output Bus Nominal
(@ 115 / 230 input) Minimum
Maximum
VDC 160 / 320
88 / 176
180 / 360
Nominal Phase Current ("10%) A
RMS
2.5 5.0 7.5 2.0 5.0 10 15
Peak Phase Current ("10%); for
2.4sec (+0.5s/--0sec) maximum ¡
A
RMS
5 10 15 4 10 20 30
Nominal Output Power KVA 1.01 2.17 2.99 0.87 2.17 4.33 5.2
Output Frequency Hz 0 -- 500
Efficiency % >95
Nominal Switching Frequency KHz 8.5
Current Loop Bandwidth Hz 1200
Velocity Loop Bandwidth Hz 10 to 200 (software selectable)
Mounting -- Panel
Package Size -- A B C E E E E
Operating Altitude Feet
(Meters)
To 3300 feet (1000 meters). Derate the continuous and
peak output current by 1.1% for each 330 feet (100
meters) above 3300 feet.
Operating Temperature #C
+0 to 40. Above 40#C, derate the continuous and peak
output current by 2.5% per #C above 40#C. Maximum
ambient is 50 #C.
Rated Storage Temperature #C -- 2 5 t o + 7 0
Humidity % 10% to 90% non-condensing
Class of Protection (Enclosure) IP20
Shock 10G (according to DIN IEC 68--2--6/29)
Vibration 1G @ 10 -- 150 Hz (according to DIN IEC 68--2--6/29)
¡ Valid for zero current initial condition.
© These specifications also apply to model FPxAxxP except it has DC input (no AC input).
All values at ambient temperature of 25#C unless otherwise stated.
For safe operation, allow a clearance distance between each control and on all sides of each control.
