Accessories & Options 9-3
MN1276
For package size E, G and H (Model T -- 3 Phase Required for FP4xx)
Filter Type Rated Volts
Rated
Amps
@40#C
Leakage
Current mA
Weight
lbs (kg)
Baldor No.
FN 3258 - 30 - 47 480 30 184.7 2.64 (1.2) ASR30521
FN 3258 - 7 - 45 480 7 172.4 0.11 (0.5) ASR30522
D
AC Filter Dimensions Continued
4.53 (115)
B
M6
Depth = F
C E
G
G
H
A
Dim. For For Filters: FN 351 -
FN350 8 - 29 16 - 29 25 - 33 36 - 33 50 - 33
A 5.4 8.6 9.45 9.84
(139) (220) (240) (250)
B 3.9 7.1 7.87 7.87
(99) (180) (200) (200)
C 4.2 4.5 5.9 5.9
(105) (115) (150) (150
D 3.32 3.35 4.7 4.72
(84.5) (85) (119.5) (120)
E 3.73 3.93 5.31 5.31
(95) (100) (135) (135)
F 2.24 2.36 2.55 2.55
(57) (60) (65) (65)
G 0.39 0.39 0.39 0.78
(10) (10) (10) (20)
H 1.74 0.76 1.22 0.83
(19) (19.5) (31) (21)
AC Filter Dimensions Continued
B
M5
A
Dim. For Filters:
FN3358- 7- 45 FN3358- 30- 47
A 7.48 10.63
(190) (270)
B 6.29 9.45
(160) (240)
C 7.08 10.04
(180) (255)
D 0.79 1.18
(20) (30)
E 0.18 0.21
(4.5) (5.4)
F 2.75 3.35
(70) (85)
G 1.57 1.97
(40) (50)
F
C
E
D
G
