1.9 Technical Data 47
Circuits Dimensions in mm (in.) Q'ty / box
A B
4 6.0 (.236) 9.8 (.386) 1.000
12 22.0 (.866) 25.8 (1.016) 1.000
Material and finish: nylon 66, UL94V-0, natural (white)
Manufacturer: JST
Part number: PHR-4 / PHR-12
See also
Suitable assembled cable accessories for mvBlueFOX-M: What's inside and accessories (p. 18)
1.9.3.1.5 Characteristics of the mvBlueFOX-Mxxx digital I/Os
Symbol Comment Min Max Unit
U
DIG_IN
Input voltage -
0.←-
3
3.6 V
1.9.3.1.5.1 Dig I/O max. values
Symbol Comment Min Nom Max Unit
U
DIG_IN_LOW
low level input voltage (I
IN
= 1.67mA) -
0.←-
3
0 0.9 V
U
DIG_IN_HIGH
high level input voltage (I
IN
= 1.67mA) 2.←-
2
3.3 3.6 V
I
IN
input current (@ 3.3V) 0.←-
4
1.7 mA
1.9.3.1.5.2 Characteristics of the digital inputs
Figure 15: Digital input mvBlueFOX-Mxxx
MATRIX VISION GmbH
