Balluff Micropulse BTL5 Series User Manual

1-800-543-8390 • www.balluff.com
10
BTL5-_-M_-J-DEXC-TA12
Micropulse Linear Position Sensor
Analog & Digital-Pulse Outputs
Explosion-Proof Rod Style
5.1 Magnets
5.2 Conduit Adapter
5 Accessories (Order Separately)
Order code BAM013L BAM013P BAM013J
Part number BTL-P-1013-4R BTL-P-1013-4S BTL-P-1012-4R
Material Aluminum Aluminum Aluminum
Weight 12 g 12 g 12 g
Order code BAM011T
Part number BTL-A-AD09-M-00-EX
Material Nickel-Plated Brass
Approvals SIRA00ATEX1094
EEx de I & IIC
I M2, II 2 GD
AEx de Class 1, Zone 1, Groups I & IIC
Class I Division 1 & 2, Groups A, B, C, D
Class II & III, Groups E, F, G
18
20
43
18.40
21.85
Dia.15
26.80
M20 Threads
½” NPT Threads
Top View
18
20
43
18.40
21.85
Dia.15
26.80
M20 Threads
½”
NPT Threads
