BTL5-_-M_-J-DEXC-TA12
Micropulse Linear Position Sensor
Analog & Digital-Pulse Outputs
Explosion-Proof Rod Style
7 Order Code
BTL5-S1_ _-M _ _ _ _-J-M01 -TA (replacement electronics module only, no pressure housing)
BTL5-S1_ _-M _ _ _ _-J-DEXC-TA12 for asynchronous operation (complete linear position sensor)
BTL5-S1_ _-B-M _ _ _ _-J-DEXC-TA12 for synchronous operation (complete linear position sensor)
Output format Resolution
Standard
nominal stroke [mm]
Connection
0 Binary code, rising (24-bit)
1 Gray code, rising (24-bit)
6 Binary code, rising (25-bit)
7 Gray code, rising (25-bit)
1 1 µm
2 5 µm
3 10 µm
4 20 µm
5 40 µm
0025...3962 mm TA12 Internal thread
modified
1/2" 14 NPT
BTL5 SSI Interface
TA12 Internal thread
modified
1/2" 14 NPT
Connection
BTL5-H1_ _-M _ _ _ _-J-M01 -TA (replacement electronics module only, no pressure housing)
BTL5-H1_ _-M _ _ _ _-J-DEXC-TA12 (complete linear position sensor)
Software configuration
1 1 × position and
1 × velocity
2 2 × position and
2 × velocity
Baud rate
0 1 Mbaud
1 800 kbaud
2 500 kbaud
3 250 kbaud
4 125 kbaud
5 100 kbaud
6 50 kbaud
7 20 kbaud
8 10 kbaud
Standard
nominal stroke [mm]
0025...3962 mm
BTL5 CANopen Interface
BTL5 Analog Interface
BTL5-_ _ _-M_ _ _ _-J-M01-TA (replacement electronics module only, no pressure housing)
BTL5-_ _ _-M_ _ _ _-J-DEXC-TA12 (complete linear position sensor)
Output signal Standard nominal stroke [mm] Connection
A51 0...10 V and 10...0 V
Rising and falling
E50 4...20 mA, rising
E57 20...4 mA, falling
C50 0...20 mA, rising
C57 20...0 mA, falling
G51 -10...10 V and
10...-10 V rising and falling
TA12 Internal thread
modified
1/2" 14 NPT
0025...4445 mm
in 1 mm increments
Programming tool for null point and end point BTL5-A-EH03
BTL5 PROFIBUS DP Interface
BTL5-T1_ 0-M _ _ _ _-J-M01 -TA (replacement electronics module only, no pressure housing)
BTL5-T1_ 0-M _ _ _ _-J-DEXC-TA12 (complete linear position sensor)
Software configuration
1 1 × position and
1 × velocity
2 2 × position and
2 × velocity
Standard nominal stroke [mm]
0025...3962 mm
Connection
TA12 Internal thread
modified
1/2" 14 NPT
