www.balluff.com • 1-800-543-8390
9
BTL5-_-M_-J-DEXC-TA12
Micropulse Linear Position Sensor
Analog & Digital-Pulse Outputs
Explosion-Proof Rod Style
4.2 Specifications
Specifications
Measurement Type Linear Displacement
Measuring Range 51 mm (2 in.) to 4445 mm (175 in.)
Connection Means Internal screw-type terminal block, Min. 26 AWG/Max. 16 AWG
Shock Rating 100 g/6 ms per IEC 68-2-27
Vibration Rating 12 g, 10 to 200 Hz per IEC 68-2-6
Environmental Protection IP68*
*To maintain the IP68 rating, ensure that the connection at the conduit opening also meets
this standard.
Thread sealant should be used on the conduit opening to ensure protection against moisture
ingress.
Take care to prevent the possibility of internal condensation in the conduit from entering the
position sensor housing.
Housing/Rod Material Stainless steel, 316L
Cover Material Stainless steel, 316L (Standard version)
Alternative: 304 Stainless Steel or Nitronics 60 or European equivalent (1.4404, 1.4571, 1.4305)
Cover O-Ring Material Viton
Pressure Rating, Rod 8700 psi (600 bar)
Standard Operating Temperature
Range
-40°C to +80°C (-40°F to +176°F) (Refer to Approvals on page 5 for application specific
temperature constraints.)
Low Temperature Operation
< -40°C (-40°F)
Protection method rated to -50°C (-58°F). Sensor functionality not assured.
Storage Temperature Range -50°C to +85°C (-58°F to +185°F) (Refer to Approvals on page 5 for application specific
temperature constraints.)
Humidity <90%, non-condensing
Electrical Performance Specifications For complete electrical and performance specifications, refer to Micropulse BTL5
B/Z-housing User Guides for the appropriate output type.
