BTL5-_-M_-J-DEXC-TA12
Micropulse Linear Position Sensor
Analog & Digital-Pulse Outputs
Explosion-Proof Rod Style
1.3 Use and inspection
The relevant safety regulations must be followed when using the linear position sensor system.
In particular, steps must be taken to ensure that should the linear position sensor system
become defective, no hazards to persons or property can result. This includes the installation
of additional safety limit switches, emergency shutoff switches and maintaining the permissible
ambient conditions.
2.1 Functional Description
The Micropulse EX Linear Position Sensor is designed to provide highly accurate position
feedback in areas containing potentially explosive gases and dusts.
The Micropulse EX Linear Position Sensor consists of:
• A heavy-duty stainless steel housing with a Modified 1/2"-14 NPT threaded conduit
opening for cable entry. Modified threading in accordance with FM Standard 3615,
Chapter 3.3.3, Paragraph D, Section 1. Manufacturer does not supply conduit.
• An internal electronics module/sensing element that provides electrical position feedback
signals in the form of an analog voltage, analog current, or digital pulse signals. The
internal electronics module/sensing element can be replaced while the external housing
stays in place.
Approvals:
2 General Information
CSA15.2411253X
Class I Zone 1 AEx db IIC T* Ga/Gb T6 Ta -50° to 65°C, T5 Ta -50° to 80°C
Class I Zone 1 Ex db IIC T* Gb T6 Ta -50° to 65°C, T5 Ta -50° to 80°C
Class I, Division 1, Groups A,B,C,D
Class II, Division 1, Groups E,F,G;
Class III T6 Ta -50° to 65°C, T5 Ta -50° to 80°C Type 4X/6P; IP68
SIRA 11ATEX1104X
IECEx SIR 11.0048X
II 1/2GD
Ex db IIC T* Ga/Gb Ta -50° to 65°C (T6) -50° to 80°C (T5)
Ex t IIIC T85/T100°C Da IP68 Ta -50° to 65°C (T85) -50° to 80°C (T100)
2813 (manufactured in the USA)
0102 (manufactured in Hungary)
