1-800-543-8390 • www.balluff.com
4
BTL5-_-M_-J-DEXC-TA12
Micropulse Linear Position Sensor
Analog & Digital-Pulse Outputs
Explosion-Proof Rod Style
Read this manual before installing and operating the Micropulse linear position sensor.
1.1 Scope
This document provides installation instructions and technical data specific to the Micropulse EX
linear position sensor. Detailed technical specifications for the electronics package can be found
in the standard Micropulse linear position sensor User’s Guides, corresponding to the relevant
type of output signal.
1.2 Safety Advisory
Read this manual before installing the Micropulse EX linear position sensor. The Micropulse EX
linear position sensor should be installed by qualified personnel and used in accordance with the
conditions for which it was designed. Any unauthorized modification could result in equipment
damage or personal injury, and is expressly forbidden.
from being adversely affected, thus
ensuring that the type of protection provided by the equipment is not compromised.
Aggressive Substances: e.g. acidic liquids or gases that may
attack metals, or solvents that may affect
polymeric materials.
Suitable Precautions: e.g. regular checks as part of routine
inspections or establishing from the
material’s data sheets that it is resistant
to specific chemicals.
9. See the diagram of the product label in section 3 of this document for appropriate
markings, ratings, and manufacture contact information.
10. The characteristics of the equipment are detailed in section 4 of this document.
i Preface - ATEX Directive Instructions (cont.)
1 Introduction
