BARCOMED CORONIS Display properties
19
BarcoMed 5MP2FH, BarcoMed Coronis or BarcoMed Coronis 5MP
for example, run in extended depth (10-bit) mode by default.
Implications: When turned on the “Disable Extended Depth” option
causes a BarcoMed Coronis display controller to run in 8-bit mode,
which results in increased performance since the frame buffer is
set to run with 8-bit pixels. While this option may be used with
applications that normally require 10-bit support, there will be a
loss of pixel depth, i.e. 256 shades of gray instead of 1024
simultaneous shades of gray.
Disable RGB To Static Gray Color Translation
Select Disable RGB To Static Gray Color Translation if you wish to have
RGB values equally weighted, with 1/3 each. When not selected, then
the International Commission on Illumination (CIE – Commission
Internationale de I’Eclairage) model will be adapted, which weights the
colors as 59% Green, 30% Red, 11% Blue.
Monitor Configuration
If the options in this section are grayed out, then they are not available
for the model controller with which you are working.
Using the BarcoMed Hardware tab
Note: The BarcoMed Hardware Tab is not available for the MXRT
family of Barco display controllers.
Device
Displays the current BarcoMed display controller, driver, and the
currently selected display resolution. There is a drop down menu which
displays the PCI bus, slot and function information associated with the
display controller you are working with.
PCI Information
Device ID: Displays the device’s PCI Device ID number.
