On-screen display (OSD)
48
Scan measurement information submenu
ULT information submenu
Name Description
DVI input Indicates the DVI format of the connected
video signal
DVI link Indicates the current DVI link format
Resolution Indicates the video signal resolution
Clock frequence Indicates the internal clock frequence
Hor. total The width of the total horizontal interval
Hor active IThe width of the horizontal active interval
Hor blanking The width of the horizontal blanking
Hor front porch The width of the horizontal front porch
Hor sync The width of the horizontal sync
Hor back porch The width of the horizontal back porch
Hor frequency The current horizontal frequency
Vert. total The width of the total vertical interval
Vert active The width of the vertical active interval
Vert blanking The width of the vertical blanking
Vert front porch The width of the vertical front porch
Vert sync The width of the vertical sync
Vert back porch The width of the vertical back porch
Vert frequency The current vertical frequency
Name Description
Status Indicates the status of the ULT circuit
