Barco ICMP Installation Manual

2. ICMP functionality
SMPTE S tandard Source
Resolution
Frame Rate Display Rate
Scan Type
SMPTE 274M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
23.976
24
25
29.97
30
Segmen ted frame
Y Cb Cr 4:2:2 10-Bit
SMPTE 274M
1920 x 1080 25
29.970
30
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 10-Bit
Dual-Link HD-SDI (SMPTE 372M) formats
SMPTE S tandard Source
Resolution
Frame Rate Display Rate
Scan Type
SMPTE 274M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
23.976
24
25
29.970
30
Progressive
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
23.976
24
25
29.970
30
Segmen ted frame
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M
1920 x 1080 25
29.970
30
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
Standard HD-SDI (2 × SMPTE 292M) formats
3
SMPTE S tandard Source
Resolution
Frame Rate Display Rate Scan Type
SMPTE 292M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
47.952
48
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
SMPTE 292M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
47.952
48
50
59.940
60
Segmen ted frame
Y Cb Cr 4:2:2 10-Bit
3. mainly used to carry stereoscopic images.
18 R5905722 ICMP 09/11/2016
