ImagePRO-II • User’s Guide 153
B. Remote Control Protocol
ImagePRO-II Remote Commands
• Parameters:
--con (connector): 0-4
0 = DVI, 1 = HD15, 2 = HDMI, 3 = DP, 4 = SDI1
--ch (channel): 0-1
--units (units): 0 = percent, 1 = pixel
--percent (If values are given in percentages, refer to PANZOOM.help
for parameter details.)
--pixel (If values are given in pixels, refer to RECT
for parameter
details.)
--save (save view settings)
--recall (recall view settings)
--reset (reset view settings)
• Query Format 1 (Unit):
VIEW --con (connector) --ch (channel) --?
• Query Response 1: View Settings in the following format
VIEW --unit (units)
• Query Format 2 (Percent):
VIEW --con (connector) --ch (channel) --percent --?
• Query Response 2: View Settings in the following format:
VIEW --hpos (h pos) --vpos (v pos) --hsize (h size)
--vsize (v size)
• Query Format 3 (Pixel):
VIEW --con (connector) --ch (channel) --pixel --?
• Query Response 1: View Settings in the following format:
VIEW --hpos (h pos) --vpos (v pos) --hsize (h size) --
vsize (v size)
