ImagePRO-II • User’s Guide 31
4. Menu Orientation
About the Status Menu
^Äçìí=íÜÉ=pí~íìë=jÉåì
The Status Menu is the ImagePRO-II’s top-level menu, which appears by default at system
startup. This menu provides input, output, and Genlock information. The following figure
illustrates a sample Status Menu.
Figure 4-7. Status Menu (sample)
Although the specific information displayed in this menu varies according to the input
selected, the Status Menu always provides the following details:
• The first line shows the format of the active input in the form Hact x Vact @ vr Hz
Example: 1280x1024p @ 59.94 Hz
If you use a custom configuration for the input, the first line shows the name of
your configuration. If the selected input does not detect a valid input signal, the
first line displays Invalid Signal.
• The second line indicates:
~ The Genlock status for the output channel. The options are:
• EXT Lock to external source
• N# Lock to input number...
• N/A Freerun (default)
~ The type of input signal being processed. Options are CVBS, YC, SDI,
RGB, YPbPr, DVI-I, HDMI and DP.
• The third line provides the output format for the available output channel.
Example: CHA: 1920x1080p @ 60
IN: 1280x1024p @59.94
Genlock: N/A DVI
CHA: 1920x1080p @60
