Barco RLM W12

22
RGBs connection
Ifthesourceequipmentusescompositeimagesynchronizedconnectorstooutput
RGB,pleaseconnectthegreen,blueandredconnectorstotheY,Pb,Prjacksatthe
COMPONENT1/SCARTinputsandthesynchronizedoutputtotheVIDEOjack.
S-VIDEO VIDEO YUV 1
RGB-S
RGBHV / YUV 2
G/Y B/Pb R/Pr H VRGB-HV/SOG
HDMI
 HDMI 
YUV 1
Synchronize
Green Blue Red
DVD player or other SCART
RGBS input sources
IR INPUT connection
IftheprojectorisunabletopickuptheIRsignalsfromtheremotecontroleduetodistanceor
obstacles(i.e.wallorcabinetdoors),youcanconnectanexternalIRrepeatertotheprojector’s
IRINPUTjacktoextendtheeffectivesignalreceptionrange.

S-VIDEO VIDEO YUV 1
RGB-S
RS-232
12V TRIGGER
IR ext.I II
350mA
RGBHV / YUV 2
G/Y B/Pb R/Pr H VRGB-HV/SOG
HDMI
 HDMI 
O
N
l
PO
WER O
F
F
▲
▼
▲
▼
USER
M
EMO
R
Y
SOURCE
IR sensor
IR repeater
Remote control
Installing the projector
