Barco RLM W12

12
Bottom view
305
160
220
532
105
152.5
CeilingMountOrderInfo:
1.R9849999-Ceilingmount
2.R9841260-ShortPulley400mmto765mm
3.R9841261-LongPulley800mmto1165mm
Adjustable foot
Adjusttheheightandangleoftheprojector
withtheadjustablefoot
Mounting bracket screw hole
Thesescrewholesareusedtomounttheprojector
toitsdesignatedmountingbracketusing3M8x15
screwsand3M8x40bolts.Thedimensionsofthe
screwholesareshownintheimagebelow.
M8x40
3bolts
M8x15
3screws
Projector parts and functions
2
