Rear projection - desktop installaion
PressMENUALIGNMENTRearProjectionandchooseON;theprojectorisnow
conguredfor“rearprojection-desktopinstallation”.

canoe
Correct Picture
canoe

canoe
Rear projection - ceiling mode
PressMENUALIGNMENTRearProjectionandchooseON;
pressMENUoncemoreALIGNMENTCeilingModeandchooseON
canoe
canoe


Correct Picture
canoe
Adjusting the projector lens
Projectorlensadjustmentincludesfocus,zoom,horizontal/verticalimageshift.Please
refertoPage15:“5.Adjustingtheprojector’sangle”.,“6.Adjustingfocusandzoom.”.and“7.
Correctingkeystoningcausedbyprojectionangle”.fordetailedinstructions.
