ALIGNMENT
Rear Projection
ThedefaultsettingisOff.
Whenyouhavesetuptheprojectorforrearprojection,pleasesetittoON.Formore
informationondifferentmodesofprojection,referto"Page17:Modesofinstallation".
Ceiling Mode
ThedefaultsettingisOff.
Whenyouhavesetuptheprojectorforceilingmode(hungfromtheceilinginreverse),please
setittoON.Formoreinformationondifferentmodesofprojection,referto"Page17:Modes
ofinstallation".
Lens Control
•
Zoom
Thisfunctionisidenticaltotheonecoveredinprevioussections.Referto"Page15:
6.Adjustingfocusandzoom.".
•
Focus
 Thisfunctionisidenticaltotheonecoveredinprevioussections.Referto"Page15: 
 6.Adjustingfocusandzoom.".
•
Shift
 Thisfunctionisidenticaltotheonecoveredinprevioussections.Referto"Page15:5.
Adjustingtheprojector'sangle".
Keystone
Usethisfunctiontocorrectkeystoningcausedbyprojectionangle.
•
Horizontal Keystone
Thisfunctionisidenticaltotheonecoveredinprevioussections.Referto"Page16:7.
Correctingkeystoningcausedbyprojectionangle".
•
Vertical Keystone
 Thisfunctionisidenticaltotheonecoveredinprevioussections.Referto"Page16:7.
Correctingkeystoningcausedbyprojectionangle".
 Note:*Thesummationoftheabsolutevalueofhorizontalkeystoneandverticalkeystoneislimitedto
 lessthanorequalto350.*
