APPENDIX. TIMING TABLE
A. SIGNAL REQUIREMENT
ALL SIGNAL MUST BE AVAILABLE WITH CHROMA
SIGNAL A FULL WHITE PATTERN, CHROMA PATTERN #41
SIGNAL B FULL BLACK PATTERN,CHROMA PATTERN #11
SIGNAL C COLOR BARS: EIGHT 100 PIXEL WIDE BARS.
SIGNAL D CROSSHATCH, CHROMA PATTERN #1.
B. TIMING OF INPUT SIGNALS
NOMINAL INPUT LEVE SPECIFICATION.
SIGNAL A. DATA VGA INPUT LEVEL
ANALOG VIDEO RGB : 0.7Vpp 75 ohm. POSITIVE.
SEPARATE SYNC : LOW =0V MIN.~0.65V MAX.
HIGH= 2.8V MIN.~5.5V MAX.
POSITIVE/NEGATIVE. 1K ohm.
COMPOSITE SYNC: LOW=0~0.65Vpp
HIGH=2.8~5.5Vpp
NEGATIVE. 1K ohm.
SIGNAL B. DVI-D (T.M.D.S) INPUT : T.M.D.S HIGH LEVEL, 1K ohm
POSITIVE.
SIGNAL C. COMPOSITE VIDEO : 1Vpp 75 ohm POSITIVE.
SIGNAL D. S-VIDEO (NTSC) : Y = 1Vpp, 75 ohm, POSITVE.
SYNC = 0.3Vpp, NEGATIVE
C = 0.286Vpp 75 ohm. POSITIVE
SIGNAL E. S-VIDEO (PAL) : Y = 1Vpp , 75 ohm, POSITIVE.
SYNC=0.3Vpp, NEGATIVE.
C = 0.3Vpp. POSITIVE
SIGNAL F. Components VIDEO : Y = 1Vpp, 75 ohm, POSITIVE.
SYNC = 0.3Vpp, NEGATIVE.
Cb = 0.7Vpp,75 ohm, POSITIVE.
Cr = 0.7Vpp 75 ohm. POSITIVE
