130 of 149
11
W12
&
W14
BME K RLM W12
FAN 5-ENGINE IN
R5001052K
12
W12
&
W14
BME K RLM W12
FAN 0 - R DMD
R5001056K
13
W12
&
W14
BME K RLM W12
FAN-R1 - FPGA
R5001057K
14
W12
&
W14
BLK RLM W12
FAN-12
R5001060K
PCBA
1
W12
&
W14
BME K RLM W12 &
W14 HORZ SENSOR
BD
R5001080K
