Barco RLM-W14 Service Manual

17 of 149
The lists of valid operation commands for BARCO RLM W14 are shown in below Table.
Barco RLM W14 Operation Commands
Command
Item
Operation
Commands
Values
Notes
1-1
input.sel
= ?
0 = HDMI
1 = HDBaseT
2 = RGB D-15
3 = YUV 1
4 = RGBHV/YUV2
5 = Reserve
6 = Reserve
7 = Reserve
8 = SDI/HDSDI/3G
9 = STEREO DVI
Note1; Note3
1-2
input.lock
= ?
0 = Auto
1 = 48 Hz
2 = 50 Hz
3 = 60 Hz
Note2
1-3
auto.powoff
= ?
0 = Off
1 = On
Note1
1-4
auto.powon
= ?
0 = Off
1 = On
1-5
no.signal
= ?
0 = Logo
1 = Blue
2 = Black
3 = White
Note1
1-6
vid.std
(Reserve)
= ?
0 = Auto
1 = PAL
2 = SECAM
3 = NTSC
Note2; Note4
1-7
auto.imgadj
= ?
0 = Off
1 = Auto
2 = Always
Note2
2-1
contrast
= ? + -
0 - 200
Note2
2-2
Bright
= ? + -
0 - 200
Note2
2-3
(Reserve)
= ? + -
0 - 200
Note2; Note4
