3-2. Troubleshooting & Error Code
Error Code Definition
In RS232 debug mode, the Main formatter board & Slave MCU will response with error code in
case of system error like lamp fail, or thermal situation failure, etc.
They are defined as below table.
Error Code Message – Troubleshooting and what parts need to replace
0
ErrMsgOverTempInlet: –Temp. is over spec. Check if there is anything
blocks in inlet or replace Inlet thermal sensor.
1
ErrMsgOverTempDMD – Temp. is over spec. Check or replace DMD thermal
sensor.
2
ErrMsgOverTempLamp1– Check or replace Lamp 1 thermal sensor state.
3
ErrMsgOverTempLamp2– Check or replace Lamp 2 thermal sensor state.
4
ErrMsgOverTempBallast1–Check and replace Ballast1 thermal state.
5
ErrMsgOverTempBallast2 –Check and replace Ballast2 thermal state.
6
ErrMsgFanInitError–Anyone fan could be error when power on. Thus, check
and replace error fan you find out. And, try to replace fan board.
7
ErrMsgFan0RotateError – Fan0 gets error during projector working. Check
and replace fan 0.
8
ErrMsgFan1RotateError – Fan1 gets error during projector working. Check
and replace fan 1.
9
ErrMsgFan2RotateError – Fan2 gets error during projector working. Check
and replace fan 2.
10
ErrMsgFan3RotateError – Fan3 gets error during projector working. Check
and replace fan 3.
11
ErrMsgFan4RotateError – Fan4 gets error during projector working. Check
and replace fan 4.
12
ErrMsgFan5RotateError – Fan5 gets error during projector working. Check
and replace fan 5.
13
ErrMsgFan6RotateError – Fan6 gets error during projector working. Check
and replace fan 6.
14
ErrMsgFan7RotateError –Fan7 gets error during projector working. Check and
