Barco RLM-W14 Service Manual

36 of 149
replace fan 7.
15
ErrMsgDMDInitFail –Check and replace main formatter board, formatter
board and DMD chip.
16
ErrMsgLampInitFail –Check and replace ballast 1.
17
ErrMsgLampLitFail –Check and replace Lamp 1.
18
ErrMsgBallastUartError –Check and replace ballast 1 and power board.
19
ErrMsgExGpioFail –Check and replace video or uc control board.
20
ErrMsgInterLockOpen–Check and confirm Interlock.
21
ErrMsgGF9450NoResponse –Check and replace video board.
22
ErrMsgSystemI2cFail –Check and replace all board.
23
ErrMsgSoftwareI2cFail –Check and replace all board.
24
ErrMsgEepromFail –Check and replace uc control board.
25
ErrMsgEdidFail–Check and replace video board.
26
ErrMsgEepVersionFail–Check and replace video board.
27
ErrMsgRstGennum –Check and replace video board.
28
ErrMsgFan8RotateError –Fan8 gets error during projector working. Check and
replace fan 8.
29
ErrMsgFan9RotateError –Fan9 gets error during projector working. Check and
replace fan 9.
30
ErrMsgFan10RotateError –Fan10 gets error during projector working. Check
and replace fan 10.
31
ErrMsgFan11RotateError –Fan11 gets error during projector working. Check
and replace fan 11.
32
ErrMsgLamp2LitFail ––Check and replace Lamp 2.
33
ErrMsgBallast2UartError ––Check and replace ballast 2 and power board.
34
ErrMsgGtInletTp ––Check or replace Inlet thermal sensor.
35
ErrMsgGtDmdTp –Check or replace DMD thermal sensor.
36
ErrMsgInletTempSensorFail––Reserved & None for this model.
37
ErrMsgDMDTempSensorFail –Reserved & None for this model.
38
ErrMsgGeoSystemFail – Check and replace the W2 board.
39
ErrMsgNormal ––Reserved & None for this model.
40
ErrMsgFan12RotateError ––Fan12 gets error during projector working. Check
and replace fan 12.
41
ErrMsgFan13RotateError –– Reserved & None for this model.
42
ErrMsgFan14RotateError –– Reserved & None for this model.
43
ErrMsgFan15RotateError –– Reserved & None for this model.
44
ErrMsgFan16RotateError –– Reserved & None for this model.
