Barco RLM-W14 Service Manual

144 of 149
TIMING OF INPUT SIGNALE
P
O
R
S
VIDEO
Q
VERTICAL
A : H-TOTAL TIME O : V-TOTAL TIME
B : H-SYNC PULSE WIDTH P : P: V-SYNC PULSE WIDTH
C : H-BACK PORCH Q : V-BACK PORCH
D : H-DISPLAY TIME R : V-DISPLAY TIME
E : H-FRONT PORCH S : V-FRONT PORCH
VIDEO
D
B
A
E
C
