4-11 Fan 20 & Fan 21 & Fan 22 & Fan 23
Loosen 3 screws on the Fan 20.
Loosen 2 screws on the Fan 20. Then, take off
Fan 20.
Loosen 2 screws on the Fan 21.
Loosen 2 screws on the Fan 21. Then, take off
Fan 21.
