4-7 Video Board & DUAL Link DVI (3D) Board
Loosen 1 screw under the right of the brace
of video Board.
Loosen 1 screw under the left of the brace of
video Board.
Take out the brace.
Unplug 1 connector and loosen 2 screws on
the DUAL Link DVI (3D) Board.
Take out the DUAL Link DVI (3D) Board.
