R5911443 /08 UDM118
Image 9–3
The Profile edit menu shows up.
Image 9–4
4. Select New profile
Image 9–5
5. Enter a suitable name for this profile via the pop up keyboard (arrow keys and OK (✓) to select). End the
name entry by selecting the “return” key on the pop up keyboard.
6. Select the “Assign to preset slot”. A drop down menu will show up, select the preferred value.
Note: The function “Assign to preset slot” enables a shortcut to the actual profile from the
remote control. If assigned preset slot are set to 1, this profile can be recalled by pressing the key
MACRO and then 01 on the remote control. It is not a requirement to use this function, just an
option.
Note: The maximum number of profile presets is 30.
7. Select the domains in the menu that shall be stored in the profile.
GUI – Profiles
